Elektro-Automatik EA-PSB 10010-510 3U
Bidirektionales Labornetzgerät
10V, 510A, 5100W
Preis auf Anfrage

EA Elektro-Automatik Bidirectional Power Supplies

The EA 10000 Series bidirectional DC power supplies bring a host of capabilities and efficiencies. Bidirectional regenerative supplies are more cost-effective and environmentally friendly because they recover energy and feed it back into the grid with >96% efficiency to reduce heat, noise and HVAC costs. True autoranging delivers maximum power across a wider range of voltage and current values while a suite of optional control interfaces enables computer control in near any manufacturing environment.



Technische Daten

Kanäle 1
Leistung 5100 W
Strom 510 A
Spannung 10 V
Programmierbar ja
Genauigkeit 0-10V ≤0.2%, 0-5V ≤0.4%
Abmessungen (H x B x T) 19" x 3U x 668 mm
Garantie1 Jahr

Datenblätter
