Elektro-Automatik EA-PSB 10080-170 3U
Bidirektionales Labornetzgerät
80V, 170A, 5000W
11'900.00 CHF (12'863.90 CHF inkl. MwSt.)

EA Elektro-Automatik Bidirectional Power Supplies

The EA 10000 Series bidirectional DC power supplies bring a host of capabilities and efficiencies. Bidirectional regenerative supplies are more cost-effective and environmentally friendly because they recover energy and feed it back into the grid with >96% efficiency to reduce heat, noise and HVAC costs. True autoranging delivers maximum power across a wider range of voltage and current values while a suite of optional control interfaces enables computer control in near any manufacturing environment.



Technische Daten

Kanäle 1
Leistung 5000 W
Strom 170 A
Spannung 80 V
Programmierbar ja
Genauigkeit 0-10V ≤0.2%, 0-5V ≤0.4%
Abmessungen (H x B x T) 19" x 3U x 668 mm
Garantie1 Jahr
