Fluke 123B/S
Fluke ScopeMeter + SCC
2 Channels - 20 MHz
3'218.90 CHF
(3'479.65 CHF incl. tax)
Simplified testing, more insight and faster electro-mechanical troubleshooting
The compact ScopeMeter® 120B Series, is the rugged oscilloscope solution for industrial electrical and electro-mechanical equipment troubleshooting and maintenance applications. It’s a truly integrated test tool, with oscilloscope, multimeter and high-speed recorder in one easy-to-use instrument. The ScopeMeter 120B Series also integrates with Fluke Connect® mobile app and FlukeView® for ScopeMeter software to enable further collaboration, data analysis and archiving of critical test information
Technical Data
| Bandwidth | 20 MHz |
| Channels | 2 |
| Memory | 512 min / points max. |
| Samplingrate | 1.25 GS/s |
| Additional Functionality | Digital Multimeter (DMM) |
| Inputs | Independently floating isolated inputs |
| Safety | CAT IV 600 V/CAT III 750 V |
| Dimensions | 259 x 132 x 55 mm |
| Weight | 1.4 kg |
| Warranty | 3 years |
