Tektronix DPO714AX 7-BW-20000
Digital Phosphor Oscilloscope 12 bit
4 Channels - 20 GHz - 125 GS/s - 500M
New
Price on request
On offer list

The 7 Series DPO now offers the world’s first 8-channel oscilloscope with bandwidths ranging from 8 GHz to 25 GHz per channel, delivering a new level of visibility into complex, multi-channel systems. Available with 4 or 8 channels, it combines unparalleled signal fidelity, high ENOB, low noise and jitter, fast measurement throughput, and the award-winning TekScope® user interface. The 7 Series DPO is designed for demanding high-speed serial, high-energy physics, and wideband RF applications. It is compatible with TekConnect™ probes and adapters.

Bandwidth ranging from 8-25 GHz and compatible with TekConnect™ probes.



Technical Data

Bandwidth 20 GHz
Channels 4
Memory 500 M - 1 or 2 G (optional)
Samplingrate 125 GS/s
Acquisitionrate >500'000 wfms/s
Protocol Analyzer NRZ, 8b10b, MIL-STD-1553, ARINC429, Audio (I2S, LJ, RJ, TDM), Automotive (CAN, LIN, FlexRay), Automotive Ethernet Signal Separation, Automotive Ethernet protocol (100Base-T1), SENT, RS-232/422/485/UART, MIPI C-PHY CSI/DSI Version 2.0/1.1/1.0, CXPI, DPHY CSI/DSI (Version 2.0/1.2), Embedded protocol (I2C, SPI), Ethernet protocol 10BASE-T, 100BASE-TX, eSPI, Ethercat protocol, eUSB2, I3C, Manchester protocol, MDIO protocol, One Wire, PCIe Gen1 Gen2 Gen3 Gen 4, Power management SPMI, PSI5, Synchronous Data Link Control, SMBUS, SPACEWIRE, SVID, USB3.2 (USB 3.0, 3.1 Gen 1, 2, 3.2 Gen 1,2)
Logic Analyzer -
Spectrum AnalyzerFFT
Function Generator100 MHz (optional)
Warranty 1 year

Data sheets

7-Series-Datasheet.pdf Tektronix Performance Scope Comparison.pdf
