Tektronix DPO714AX 7-BW-8000
Digital Phosphor Oscilloscope 12 bit
4 Channels - 8 GHz - 125 GS/s - 500M
New
Price on request
On offer list

The 7 Series DPO now offers the world’s first 8-channel oscilloscope with bandwidths ranging from 8 GHz to 25 GHz per channel, delivering a new level of visibility into complex, multi-channel systems. Available with 4 or 8 channels, it combines unparalleled signal fidelity, high ENOB, low noise and jitter, fast measurement throughput, and the award-winning TekScope® user interface. The 7 Series DPO is designed for demanding high-speed serial, high-energy physics, and wideband RF applications. It is compatible with TekConnect™ probes and adapters.

Bandwidth ranging from 8-25 GHz and compatible with TekConnect™ probes.



Technical Data

Bandwidth 8 GHz
Channels 4
Memory 500 M - 1 or 2 G (optional)
Samplingrate 125 GS/s
Acquisitionrate >500'000 wfms/s
Protocol Analyzer NRZ, 8b10b, MIL-STD-1553, ARINC429, Audio (I2S, LJ, RJ, TDM), Automotive (CAN, LIN, FlexRay), Automotive Ethernet Signal Separation, Automotive Ethernet protocol (100Base-T1), SENT, RS-232/422/485/UART, MIPI C-PHY CSI/DSI Version 2.0/1.1/1.0, CXPI, DPHY CSI/DSI (Version 2.0/1.2), Embedded protocol (I2C, SPI), Ethernet protocol 10BASE-T, 100BASE-TX, eSPI, Ethercat protocol, eUSB2, I3C, Manchester protocol, MDIO protocol, One Wire, PCIe Gen1 Gen2 Gen3 Gen 4, Power management SPMI, PSI5, Synchronous Data Link Control, SMBUS, SPACEWIRE, SVID, USB3.2 (USB 3.0, 3.1 Gen 1, 2, 3.2 Gen 1,2)
Logic Analyzer -
Spectrum AnalyzerFFT
Function Generator100 MHz (optional)
Warranty 1 year

Data sheets

7-Series-Datasheet.pdf Tektronix Performance Scope Comparison.pdf

Accessories

Tektronix P7708

TriMode Differential Probe with TekFlex
8GHz - TekConnect Interface
Bandwidth 8 GHZ
Voltage ±15 V
Interface TekConnect
Attenuation 1:4 / 1:10
Price on request
On offer list

Tektronix 7-RL-1

Extend Record Length to 1 Gpts/ch for 7-Series Oscilloscopes
Price on request
On offer list

Tektronix 7-RL-2

Extend Record Length to 2 Gpts/ch for 7-Series Oscilloscopes
Price on request
On offer list

Tektronix 7-AFG

100 MHz Arbitrary Function Generator for DPO714AX Oscilloscopes
Price on request
On offer list

Tektronix 7-DJA

Advanced Jitter and Eye Analysis Option for 7-Series Oscilloscopes
Price on request
On offer list

Tektronix 7-WIN

Removable SSD with Windows License
Price on request
On offer list

Tektronix HC7

Hard Transit Case for 7-series Oscilloscope
Price on request
On offer list

Tektronix RM7

Rackmount Kit for the 7 Series Oscilloscope
Price on request
On offer list

Tektronix 7-LNX-UP

Additional removable SSD with embedded OS
one included standard with instrument
Price on request
On offer list

Tektronix 7-SREMBD

Embedded Serial Triggering and Analysis Module (SPI, I2C)
Price on request
On offer list

Tektronix 7-SRENET

Ethernet Serial Triggering and Analysis Module (10BASE-T, 100BASE-TX)
Price on request
On offer list

Tektronix 7-SRESPI

Serial Decoding and Analysis for eSPI
Enhanced Serial Peripheral Interface
Price on request
On offer list

Tektronix 7-SRETHERCAT

Serial Decoding and Analysis for Ethercat
Price on request
On offer list

Tektronix 7-SREUSB2

Serial Decoding and Analysis for eUSB2
Price on request
On offer list

Tektronix 7-SRI3C

Serial Decoding and Analysis for I3C
Price on request
On offer list

Tektronix 7-SRMANCH

Serial Decoding and Analysis
for Manchaster
Price on request
On offer list

Tektronix 7-SRMDIO

Serial Decoding and Analysis for
MDIO - Management Data Input/Output
Price on request
On offer list

Tektronix 7-SRNRZ

NRZ Protocol Decoder and Search
Price on request
On offer list

Tektronix 7-SRONEWIRE

Serial Decoding and Analysis for One wire
Price on request
On offer list

Tektronix 7-SRPCIE321

Serial Decoding and Analysis for PCIe Gen1 Gen2 Gen3
Price on request
