Fluke Ti401 PRO 9Hz
Thermal Imager 9 Hz Wireless Autofocus
7'878.70 CHF
(8'516.85 CHF incl. tax)
- Choose the thermal camera that gives you in-focus images in a matter of seconds. LaserSharp™ Auto Focus uses a built-in laser distance meter that calculates and displays the distance from your designated target and immediately adjusts the focus.
- See small details in the image and discover anomalies faster with 640 x 480 resolution thermal images
- On the thermal camera, adjust the level of infrared and visible light with patented IR-Fusion™ technology
- Manage data, capture multiple measurements (mechanical, electrical and thermal) and organize them by piece of equipment with Fluke Connect™ software
- Simply the best optics to transmit energy and produce high quality infrared images. Fluke thermal cameras use only 100% diamond-turned germanium lenses with specialty coatings.
Technical Data
| Application | for Industrial-Commercial Use |
| Detector type | 640 x 480 |
| Total pixels | 307'200 |
| Minimum focus distance | 15 cm |
| Temperature measurement range | -20 °C bis +650 °C |
| Thermal sensitivity (NETD) | ≤ 0.075 °C at 30 °C target temp (75 mK) |
| Temperature measurement accuracy | ± 2 °C or 2 % |
| Image capture frequency | 9 Hz |
| Display (touchscreen) | 8.9 cm (3.5 in) diagonal landscape color VGA (640 x 480) LCD with backlight |
| Field of view | 34° x 24° |
| Connectivity | Wireless, USB |
| Software | SmartView® and SmartView Mobile App - full analysis and reporting software included |
| Power | Li-Ion Battery |
| Enclosure rating | IP 54 |
| Weight | 1.04 kg |
| Dimensions | 277 x 122 x 167 mm |
| Warranty | 2 years |
Data sheets
Accessories
Fluke TI EYEPIECE
Price on request
On offer list
Fluke LENS/TELE2
Fluke LENS/WIDE2
Fluke LENS/4XTELE2
Fluke TI-SBP3
Fluke TI-SBC3B
Fluke Ti-Visor3
Fluke Ti-Tripod3
Fluke CV200
Fluke CV300
Fluke CV301
Fluke CV400
Fluke CV401
1 - 13 from 13
