Patented extendable tip sheath that meet new electrical safety requirements to reduce
tip exposure while providing the versatility needed for most measurements
• New WearGuard™ lead wire wear indication. Each test lead is covered by two layers of silicone insulation; inner
contrasting color is exposed when the leads are nicked, scuffed, or otherwise damaged and in need of replacement
• Double insulated silicone leads. TL175 withstands high temperatures and remain fl exible in cold temperatures.
• Extra-heavy strain relief on both probe-end and plug-end, testing beyond 30,000 bends without failure.
• Universal input plugs compatible with all instruments that accept standard 4 mm shrouded banana plugs
• Ratings: CAT II 1000 V, CAT III 1000 V, CAT IV 600 V, 10 A max., Pollution Degree 2
• TL175E includes removable 4 mm lantern tips for versatility
• Probes always show correct category rating for tip being used
• Environmental ratings: -20 °C to 55 °C, altitude: 2000 m
• Conforms to latest safety standard EN61010-031: 2008
• One-year warranty
• Also available as Test Probe Set, TP175 and TP175E
