Fluke Ti401 PRO 9Hz

Thermal Imager 9 Hz Wireless Autofocus

-10%

7'668.50 CHF 6'901.20 CHF

(7'460.20 CHF incl. tax)

Choose the thermal camera that gives you in-focus images in a matter of seconds. LaserSharp™ Auto Focus uses a built-in laser distance meter that calculates and displays the distance from your designated target and immediately adjusts the focus.
See small details in the image and discover anomalies faster with 640 x 480 resolution thermal images
On the thermal camera, adjust the level of infrared and visible light with patented IR-Fusion™ technology
Manage data, capture multiple measurements (mechanical, electrical and thermal) and organize them by piece of equipment with Fluke Connect™ software
Simply the best optics to transmit energy and produce high quality infrared images. Fluke thermal cameras use only 100% diamond-turned germanium lenses with specialty coatings.

Application	for Industrial-Commercial Use
Detector type	640 x 480
Total pixels	307'200
Minimum focus distance	15 cm
Temperature measurement range	-20 °C bis +650 °C
Thermal sensitivity (NETD)	≤ 0.075 °C at 30 °C target temp (75 mK)
Temperature measurement accuracy	± 2 °C or 2 %
Image capture frequency	9 Hz
Display (touchscreen)	8.9 cm (3.5 in) diagonal landscape color VGA (640 x 480) LCD with backlight
Field of view	34° x 24°
Connectivity	Wireless, USB
Software	SmartView® and SmartView Mobile App - full analysis and reporting software included
Power	Li-Ion Battery
Enclosure rating	IP 54
Weight	1.04 kg
Dimensions	277 x 122 x 167 mm
Warranty	2 years
